LED dash lights

Years ago I installed blue LED lights in the dash of my truck. I got them from superbrightleds.com Money and time well spent because it looks great to me. I'm wanting to do the same thing to my KLR. I don't ride it much at night but even at dusk it should look nice.

Does anyone know how many bulbs I need to order and which ones? I think I'd just replace the main dash lights.

Kawasaki KLR650 - Adventure Lite
Tagged KTM250XCF-W - Rocket
Tagged KLX300 - Trail Tractor
'84 XR250R - Retro Ride
RMZ250 - Dirty
CRF80 - Kids
CRF70 - Kids
Savage is offline
Sponsored Links
Advertisement

post #2 of 19 Old 11-10-2011, 09:28 PM
3rd Gear

Crazy Jake's Avatar

Join Date: Nov 2010
Location: Woodstock CT
Posts: 663
Man that would be cool..... Let me know how it works out.
Jake
Crazy Jake is offline
post #3 of 19 Old 11-11-2011, 02:50 AM
1st Gear

Two Trackin Fool's Avatar

Join Date: Oct 2011
Location: Wadhams MI.
Posts: 36
09' has three bulbs. One per gauge the standard bulb # is 194.

I'm planing total LED except headlights over this winter.

Last edited by Two Trackin Fool; 11-11-2011 at 02:56 AM.
Two Trackin Fool is offline

post #4 of 19 Old 11-11-2011, 08:03 PM Thread Starter
4th Gear

Savage's Avatar

Join Date: Apr 2011
Location: Kansas
Posts: 1,205
Garage
That's it? I had it off once to lube up the sticky odometer but don't remember how many bulbs I saw back there.

Kawasaki KLR650 - Adventure Lite
Tagged KTM250XCF-W - Rocket
Tagged KLX300 - Trail Tractor
'84 XR250R - Retro Ride
RMZ250 - Dirty
CRF80 - Kids
CRF70 - Kids
Savage is offline
post #5 of 19 Old 11-14-2011, 02:59 AM
1st Gear

Two Trackin Fool's Avatar

Join Date: Oct 2011
Location: Wadhams MI.
Posts: 36
I'm thinking a total of 6 including turn,neutral,bright. But I could be wrong it was earlie this season when I did the headlights.

Maybe some one else could chime in to make sure .
You could pop off the winshield and check real quick .
Two Trackin Fool is offline
post #6 of 19 Old 11-15-2011, 07:00 PM
1st Gear

desertduster's Avatar

Join Date: Oct 2010
Location: Tucson, AZ
Posts: 37
I did a little write up at [klrforum (dot) com/showthread.php?t=11623].

Three bulbs are used for background lights. I tried green for a while and decided I liked the white bulbs better. I did replace the Neutral, Turn, and Bight indicators too since the stock 194 bulbs are not bright enough; but be careful not to go too bight or you will be blinded at night.


Gauge Lighting WLED-W, 120 degrees, 3 lumens, white. Great for gauge lighting.

Find the color you want based on the above part number.
superbrightleds (dot) com

I can't post a URL until I reach 15 posts. Stinkin rule.

Ron
09 KLR

Last edited by desertduster; 11-16-2011 at 06:32 PM.
desertduster is offline
post #7 of 19 Old 11-15-2011, 08:43 PM Thread Starter
4th Gear

Savage's Avatar

Join Date: Apr 2011
Location: Kansas
Posts: 1,205
Garage
I have 2 blue leds laying around from superbright. I looked at them and found some that look identical on ebay and ordered a 10 pack of them for cheap.
So it takes (4) 194's to light up the main dash? I'll try to take some pics whenever they show up and I get around to it.

Kawasaki KLR650 - Adventure Lite
Tagged KTM250XCF-W - Rocket
Tagged KLX300 - Trail Tractor
'84 XR250R - Retro Ride
RMZ250 - Dirty
CRF80 - Kids
CRF70 - Kids
Savage is offline
post #8 of 19 Old 11-16-2011, 06:47 PM
1st Gear

desertduster's Avatar

Join Date: Oct 2010
Location: Tucson, AZ
Posts: 37
KLR650 rear instrument panel clsuter

Here is a photo of the rear cluster. The four along the bottom are turn, high beam, background, and neutral indicators.


Ron
09 KLR
desertduster is offline
post #9 of 19 Old 11-18-2011, 09:58 AM
2nd Gear

thetable's Avatar

Join Date: Dec 2009
Location: Loudoun, VA
Posts: 303
When I went hunting mA, I swapped all bulbs for LEDs.

I wanted red to keep from killing my night vision, and it is pretty hard to read at night, but it doesn't affect night vision at all. To get even lighting, the bottom bulb under the odometer needed to be a bit brighter.

From SuperBright, I got:
2x WLED-R-120
1x WLED-RHP

If I were to do it again, I would probably go with green, white, or amber, because the red just doesn't work well with the stock coloring of the gauges.

I also did the indicator bulbs with the same WLED-G-120 (Yep went green all the way across, even the high beam indicator), and that is about perfect for stock replacements. Since they are non polarized, even the turn signal indicator work just fine.
thetable is offline
post #10 of 19 Old 11-19-2011, 10:52 AM
1st Gear

desertduster's Avatar

Join Date: Oct 2010
Location: Tucson, AZ
Posts: 37
Quote:
Originally Posted by thetable View Post
When I went hunting mA, I swapped all bulbs for LEDs.

I wanted red to keep from killing my night vision, and it is pretty hard to read at night, but it doesn't affect night vision at all. To get even lighting, the bottom bulb under the odometer needed to be a bit brighter.

From SuperBright, I got:
2x WLED-R-120
1x WLED-RHP

If I were to do it again, I would probably go with green, white, or amber, because the red just doesn't work well with the stock coloring of the gauges.

I also did the indicator bulbs with the same WLED-G-120 (Yep went green all the way across, even the high beam indicator), and that is about perfect for stock replacements. Since they are non polarized, even the turn signal indicator work just fine.
I never did try the green LED for the High Beam since the cover is blue. That is great that it works there too.

Ron
09 KLR
desertduster is offline
